Inverse Kinematics

V · EThis is an official VRChat information page!

It is reviewed and approved by the VRCWiki Team. Learn how to contribute to this page by reading the Contribution Guide.

Inverse Kinematics (IK) are the animations and movements of an avatar within VRChat. VRChat currently utilizes IK 2.0, a "complete revamp" for every aspect of tracking in VRChat; including support for more tracking points, calibration saving, newer IK settings, and more.

Overview

VRChat's official render, for the release of IK 2.0

Any avatar that can animate or uses any form of movement tracking, has a 'skeleton', a virtual structure inside an avatar with a set of 'bones', that can move, and rotate. Avatar movement and animations are created by rotating the angles of joints in a skeleton to predetermined values. Most avatar features within VRChat relate to Inverse Kinematics in some way.

IK 2.0 was introduced on May 25, 2022, just shortly after the release of Avatar Dynamics and Physbones in April 2022. The releases of IK 2.0 and Avatar Dynamics, have drastically improved the quality of avatar movements, and flexibility.

IK settings within VRChat

For more detailed information, see also Settings#Tracking_&_IK.

Face Tracking

Name	Values	Tooltip
Enable Selfie Expression	On/Off	Selfie Expression uses your camera to animate your avatar! No one will see your real face. Image data is processed locally on your divce, only used for animation, and never saved.
Auto-Adjust Selfie Expression Quality	On/Off	Automatically adjust Selfie Expression quality depending on current frame rate
Selfie Expression Quality Level	Best Quality/High Quality/Balanced/Performance/Off	[Best Quality] Quality - Selfie Expression uses camera with highest resolution and framerate [High Quality] Quality - Selfie Expression uses camera with higher resolution and framerate [Balanced] Balanced - Selfie Expression uses camera with medium resolution and framerate [Performance] Performance - Selfie Expression disables hand tracking and uses minimum camera resolution and framerate [Off] Off - Selfie Expression is disabled until frame rate improves
Selfie Expression Also Moves Hands	On/Off	While Selfie Expression is enabled, and the Quality setting is set to 'Balanced' or above, allow moving hands via your webcam
Auto Recentering Speed	0-100	Adjust how quickly your avatar will automatically recenter rotation (to compensate your camera offset)
Recenter	-	Instantly recenter your avatar to compensate for camera offset
Reset	-	Reset to default
Change Webcam Device	-	Change your current webcam device. Makes sure your webcam is not being used by other software

Eye Tracking

Name	Values	Tooltip
Force Eyetracking Raycast	On/Off	When eyetracking is active, force eyes to converge at a distance determined by raycast hit
Display Eyetracking Debug	On/Off	When eyetracking is active, display debug overlay information
Disable Eye Look Tracking	On/Off	Disable tracking eye look direction
Disable Eye Lid Tracking	On/Off	Disable tracking eyelid closed amount
Mic Mute Disabled Eyetracking	On/Off	The in-app mic mute function will disable eyetracking as well (when not using push-to-talk mode)

Finger Tracking

Name	Values	Tooltip
Jump Gesture	On/Off	Enable or Disable jump Gesture
Grab Gesture	Grab/Pinch/Combined	Choose finger grab gesture

Calibration & Debug

Name	Values	Tooltip
Legacy Calibration	On/Off	Toggles using the old locked avatar position style of FBT calibration
One Handed Calibration	On/Off	Only require holding a single trigger rather than both when finalizing FBT calibration
Display Calibration Visuals	On/Off	Display extra detail during FBT calibration, Adjust FBT mode, and eyetracking debug
IK Debug Logging	On/Off	Adds additional output to the log regarding IK
Per-Avatar Calibration Adjustment	On/Off	Changes made in Adjust FBT mode will be applied per-avatar
Allow Sending Head and Wrist VR Tracking OSC Data*	On/Off	Send VR system head and wrist OSC data
Calibration Range	0.05-2.00m	Determines the distance from predicted supported binding points that the caliibration will search (in meters). The closest binding point to the center of the search sphere will be used.
Confirm Calibration	On/Off	Confirmation dialogs when clicking the "Calibrate FBT" button are [enabled/disabled], click to [disable/enable].
FBT Tracker Model	Sphere, System, Box, Axis	Switch tracker model [Sphere] Sphere - Your trackers will display as the classic default white ball [System] System - Your trackers will display using models provided by your VR system [Box] Box - Your trackers will display as boxes with colored sides representing standard xyz axis colors (lighter colors for positive direction) [Axis] Axis - Your trackers will display with axis aligned protrusions with colored tips representing standard xyz axis colors (lighter colors for positive direction)

*Footnote regarding the Allow Sending Head and Wrist VR Tracking OSC Data option: Legal Disclaimer: You are enabling a feature that will share data about you with third-party services and devices using the OSC network protocol. if you proceed, you are expressly directing VRChat to share data from your headset and other accessories with services and devices that you configure to receive such data. You can turn off this feature at any time in the "Tracking & IK" main menu options page.

Body Tracking

Name	Values	Tooltip
User Real Height	(3'0"-8'0" ft)/(0.81m-2.44m)	User Real Height should always be set to your height in real life. its important for properly matching your avatar with your body.
Metric Units Adjustment	On/Off	Adjustment arrows for User Real hight increment in cm instead of inches Adjustment arrows for User Real hight increment in inches instead of cm
Use Legacy IK Solving	On/Off	[Off] Now using new IK2.0 [On] Now using old legacy IK
Disable Shoulder Tracking	On/Off	Prevents arm trackers from affecting shoulders. Use this to avoid issues with some types of IMU-only based arm trackers
Freeze Tracking on Disconnect	On/Off	Cause trackers to freeze in place relative to the user when they are disconnected
Shoulder Width Compensation	On/Off	Assists in straightening the arm when reaching upwards on avatars with narrow shoulders
FBT Locomotion Animation	On/Off	FBT locomotion animation is [enabled/disabled] click to [enable/disable]
Tracker Motion Prediction	0-100%	Set how much latency compensating moton prediciton to use on body trackers, only works for SteamVR trackers.
Wrist Angle	-45° to 45°	Offsets the angle of the wrist alignment toward or away from the thumb
Arm vs Height Ratio	30-60%	Adjusts the ratio used to scale the avatar when using mesure-by-arms mode
Knee Angle	-180° to 180°	Offsets the knee-bend angle as predicted by the foot angle. Ignored if knee trackers are used.

In the SDK

A screenshot within Unity, to highlight VRChat SDK's various options for Inverse Kinematics.

Within Unity, an avatar's skeleton can be inspected and rigged. Within the VRChat SDK, any IK animations can be edited. In addition, PhysBones and SquishyBones can be placed onto the avatar.

Within the VRC Avatar Descriptor component on an avatar, various settings are effected by an avatar's skeleton and inverse kinematics, such as:

• Eye Look
• Playable Layers
  • Bases
    • Base: Locomotion
    • Additive: Idle
    • Gestures
    • Actions
    • FX
  • Special
    • Sitting
    • TPose
    • IKPose
• Lower Body
  • Use Auto-Footsteps for 3 and 4 point tracking
  • Force Locomotion animations for 6 point tracking
• Colliders

Physbones

For more detailed information, see also PhysBones.

Physbones are an avatar feature that utilizes VRChat's inverse kinematics system. An avatar with Physbones enabled take a bone, or set of bones on an avatar, and display additional motion beyond the normal skeletal movements. A physbones component can be enabled on an avatar's hair, clothing, tails, ears, and more, allowing those features to simulate physics, and be affected by movement, gravity, and collisions.

Avatar Dynamics

For more detailed information, see also Avatar Dynamics.

Certain avatar dynamics tie in with Inverse Kinematics! Certain toggles, interactives, and animations can be triggered on an avatar's skeleton, or by an avatar's collider.

Official resources

• IK 2.0 Features and Options on docs.vrchat.com.
• Unity Manual: Inverse Kinematics on docs.unity3d.com
